Shadow highlight
Last updated
Shadow highlight is a Colour effect.
What it does
Section titled “What it does”The effect lifts dark regions of a picture, and can pull bright regions down.
Whether a pixel counts as a shadow or highlight is based on how bright its surroundings are, and not just its own brightness.
Parameters
Section titled “Parameters”| Parameter | Control | Range | Default | Unit |
|---|---|---|---|---|
| Shadow amount | Slider | 0 to 100 | 25 | Per cent |
| Shadow tonal width | Slider | 0 to 100 | 50 | Per cent |
| Highlight amount | Slider | 0 to 100 | 25 | Per cent |
| Highlight tonal width | Slider | 0 to 100 | 50 | Per cent |
| Radius | Slider | 0 to 500; up to 2000 | 30 | Pixels at composition size |
| Colour correction | Slider | -100 to 100; higher | 20 | Per cent |
| Midtone contrast | Slider | -100 to 100; higher | 0 | Per cent |
| Mix | Slider | 0 to 100 | 100 | Per cent |
| Blend | Dropdown | Normal · Darken · Multiply · Colour burn · Linear burn · Darker colour · Add · Lighten · Screen · Colour dodge · Lighter colour · Overlay · Soft light · Hard light · Linear light · Vivid light · Pin light · Hard mix · Difference · Exclusion · Subtract · Divide · Hue · Saturation · Colour · Luminosity | Normal | - |
| Matte | Layer | Any layer in the composition | None | - |
| Invert | Checkbox | On or off | Off | - |
| Channel | Dropdown | Luminance · Alpha · Red · Green · Blue | Luminance | - |
In the Effect Controls panel:
- More options groups Colour correction, Midtone contrast, and starts closed.
- Matte scales Shadow amount and Highlight amount per pixel: white applies both in full, black neither. Invert reads that matte inverted.
What each control does
Section titled “What each control does”- Shadow amount: amount to lift dark regions.
- Shadow tonal width: range that counts as a shadow.
- Highlight amount: amount to pull down highlight regions.
- Highlight tonal width: range that counts as a highlight.
- Radius: the area to compare against to determine if a pixel is a shadow/highlight.
- Colour correction: how much saturation is added back where the picture was adjusted.
- Midtone contrast: adjusts contrast of mid-tones, since they can otherwise end up crushed.
- Mix: how much of the result replaces the original.
- Matte and Invert drive the strength of the effect from another layer’s brightness; see Effects.
